Copper coil
Normatives
Components
Nickel-plated copper pipe with Ø 8 mm external diameter, Ø 4 mm internal, length 800 mm.
Inlet and outlet fittings made of nickel-plated CW614N brass, with a specific thread for the type of gas.
NBR O-ring.
NYLON gasket.
Maintenance kit
Technical data
| CODE | GAS | LENGHT | INLET CONNECTION | INLET - OUTLET CONNECTION | P max. |
| CS040 | O2 CO2 (I) | 1 m | W21,7x1/14" 'A' | W21,7x1/14" 'A' | 230 bar |
| CS040D | O2 (D-B-EE-BG) Ar/He/CO2 (EE) | 1 m | G 3/4" 'A' | W21,7x1/14" 'A' | 230 bar |
| CS040F | O2 (F) | 1 m | SI22,91x1,814 'B' | W21,7x1/14" 'A' | 230 bar |
| CS041 | N2 (I) | 1 m | W21,7x1/14" 'B' | W21,7x1/14" 'A' | 230 bar |
| CS041D | N2 (D-NL-RS-SI-HU-BG) Ar/He (NL) | 1 m | W24,32x1/14" 'A' | W21,7x1/14" 'A' | 230 bar |
| CS042D | CO2/Ar/He (D-RS-HR-SI-HU-BG) O2 (RS-HRSI- EE-HU) CO2 (EE) N2 (HR) |
1 m | W21,80x1/14" 'A' | W21,7x1/14" 'A' | 230 bar |
| CS042F | CO2/Ar/He/N2 (F) | 1 m | SI21,7x1,814" 'A' | W21,7x1/14" 'A' | 230 bar |
| CS042UK | CO2 (UK) | 1 m | W0,860"x14T 'A' | W21,7x1/14" 'A' | 230 bar |
| CS043 | Ar/He (I) | 1 m | W24,51x1/14" 'B' | W21,7X1/14" 'A' | 230 bar |
| CS044 | H2/CH4 (I) | 1 m | W20x1/14" LH 'A' | W20x1/14" LH 'A' | 230 bar |
| CS044D | H2/CH4/C3H8 (D) | 1 m | W21,8x1/14" LH 'A' | W20x1/14" LH 'A' | 230 bar |
| CS044F | H2/CH4/C3H8 (F) | 1 m | SI21,7x1,814 LH 'A' | W20x1/14" LH 'A' | 230 bar |
| CS044UK | H2/CH4/C3H8 (UK) | 1 m | G5/8" BS LH 'B' | W20x1/14" LH 'A' | 230 bar |
| CS045 | AIR (I) | 1 m | W30x1/14" 'A' | W21,7x1/14" 'A | 230 bar |
| CS045D | AIR (D-RS) O2 (B-NL) | 1 m | G5/8" DIN 'B' | W21,7x1/14" 'A | 230 bar |
| CS045F | AIR (F) | 1 m | SI30x1,75 'A' | W21,7x1/14" 'A | 230 bar |
| CS045UK | O2/AIR/Ar/He/N2 (UK) | 1 m | G5/8" BS 'B' | W21,7x1/14" 'A | 230 bar |
| CS046 | C3H8 (I) | 1 m | W20x1/14" LH 'A' | W20x1/14" LH 'A' | 230 bar |
