Manifold copper connection

Product description

Copper connection fitting for connecting two high pressure ramps or at the inlet of the decompression panel. The swivel nuts are gas specific threads in accordance with the standards.

Components
Normatives
Technical data

Normatives

EN ISO 7396-1 | ISO 5145 | EN ISO 21969 | EN ISO 15001 | UNI 11144

Components

High pressure nickel-plated copper pipe with external diameter Ø 10 mm, internal diameter Ø 5 mm, linear length 650 mm. Brass inlet and outlet connectors with specific threading and seal according to the gas.

Maintenance kit

Technical data

CODE	GAS	LENGTH	CONNECTION	WEIGHT	P.MAX
CS101	Comburents - Inerts	0.65 m	W21,7x1/14" 'A' - W21,7x1/14" 'A'	0.60 kg	200 bar
CS102	Fuels	0,65 m	W20x1/14" LH 'A' - W20x1/14" LH 'A'	0.60 kg	200 bar
