SS 8752430 probe
Product description
The DIN probe is DIN 13260-2 standard compliant; the probe can be used to supply the desired medical gas from the clinic-hospital system.Each probe is a different size so they can't be swapped and each individual probe can be assigned to the corresponding gas take-off.All materials are oxygen compatible, supplied clean and free of any traces of oil, grease or dust.
Normatives
EN ISO 9170-1 | EN ISO 15001 | SS 8752430Components
CW617N chemically nickel-plated brass body, specific for each gas.
Gas type stamped on body.
Maintenance kit
Technical data
| CODE | GAS | OUTLET | CONNECTION | WEIGHT |
| HI112SSA4 | Air | In line | Hose connector Ø10 | 0.02 kg |
| HI112SSA8 | Air-800 | In line | Hose connector Ø10 | 0.02 kg |
| HI112SSCD | CO2 | In line | Hose connector Ø8 | 0.02 kg |
| HI112SSM1 | Mix 1 | In line | Hose connector Ø8 | 0.02 kg |
| HI112SSN4 | N2 400 | In line | Hose connector Ø8 | 0.02 kg |
| HI112SSNO | N2O | In line | Hose connector Ø8 | 0.02 kg |
| HI112SSOX | O2 | In line | Hose connector Ø8 | 0.02 kg |
| HI112SSVA | Vac | In line | Hose connector Ø12 | 0.02 kg |
| HI113SSA4 | Air | In line | G1/4" F R | 0.03 kg |
| HI113SSA8 | Air-800 | In line | G1/4" F R | 0.03 kg |
| HI113SSCD | CO2 | In line | G1/4" F R | 0.03 kg |
| HI113SSM1 | Mix 1 | In line | G1/4" F R | 0.03 kg |
| HI113SSN4 | N2 400 | In line | G1/4" F R | 0.03 kg |
| HI113SSNO | N2O | In line | G1/4" F R | 0.03 kg |
| HI113SSOX | O2 | In line | G1/4" F R | 0.03 kg |
| HI113SSVA | Vac | In line | G1/4" F R | 0.03 kg |
