LEAF SOCKET - SS 8752430
Product description
The new LEAF SS terminal units in agreement to SS 8752430 meets the requirements of functionality, security, innovation and design; the socket has a brass body and a male clutch locking system with steel balls; the coupling flange with the base is adjustable to be able to position the terminal in the desired orientation; the fixing on the base block is simple and it has quick maintenance thanks to the change of one single pre-assembled cartridge; thanks to the incorporated NFC system, traceability is facilitated and the management of maintenance thanks to the MyBehringer App to be installed on your smartphone.
Normatives
EN ISO 9170-1 | EN ISO 15001 | SS 8752430Components
Socket and base made of CW614N chemically nickel-plated brass.
Release ring nut.
Stainless steel springs.
EPDM perox O-Ring.
Maintenance kit
| CODE | GAS | DESCRIPTION |
| HK210SS07 | O2 - Air - Air-800 - Ar - CO2 - N2O - O2/N2O | MAINTENANCE CARTRIDGE LEAF SS SOCKET diam. 7 - N ° 5 |
| HK210SS09 | Vac | MAINTENANCE CARTRIDGE LEAF SS SOCKET diam. 9 - N ° 6 |
Technical data
| CODE | GAS | FLOW RATE | MAXIMUM PRESSURE DROP | WEIGHT |
| HP301SSA4BEH | Air | 40 l/min | 0,15 bar | 0.11 kg |
| HP301SSA8BEH | Air-800 | 350 l/min | 0,70 bar | 0.11 kg |
| HP301SSCDBEH | CO2 | 40 l/min | 0,15 bar | 0.11 kg |
| HP301SSM1BEH | Mix O2/N2O | 40 l/min | 0,15 bar | 0.11 kg |
| HP301SSN4BEH | N2 | 40 l/min | 0,15 bar | 0.11 kg |
| HP301SSNOBEH | N2O | 40 l/min | 0,15 bar | 0.11 kg |
| HP301SSOXBEH | O2 | 40 l/min | 0,15 bar | 0.11 kg |
| HP301SSVABEH | Vac | 25 l/min | 0,15 bar | 0.11 kg |
Images
