LEAF BASE BLOCK - SIDE PIPE
Product description
The base block of the LEAF terminal unit line is suitable for all sockets of all standards: NF-S 90-116, BS 5682, DIN 13260-2 and SS 8752430; simple installation and quick maintenance, the base block is adjustable in 6 positions thanks to the provision of n° 6 holes for fixing, once the base block is fixed the socket can be rotated to the correct position; the pipe is on the side of the base block.
Normatives
EN ISO 7396-1 | EN ISO 9170-1 | EN ISO 15001Components
Base block in brass.
Specific gas bracket in AISI316.
Sphere in AISI316.
O-Ring in EPDM PEROX.
Copper tube external Ø 8mm.
ABS cap
Maintenance kit
Technical data
| CODE | GAS | Ø PIPE | WEIGHT |
| HP300A4SP | Air | Ø 8 mm | 0.13 kg |
| HP300A8SP | Air-800 | Ø 8 mm | 0.13 kg |
| HP300ARSP | Ar | Ø 8 mm | 0.13 kg |
| HP300CDSP | CO2 | Ø 8 mm | 0.13 kg |
| HP300M1SP | Mix O2/N2O | Ø 8 mm | 0.13 kg |
| HP300N4SP | N2 | Ø 8 mm | 0.13 kg |
| HP300NOSP | N2O | Ø 8 mm | 0.13 kg |
| HP300O9SP | O2 93 | Ø 8 mm | 0.13 kg |
| HP300OXSP | O2 | Ø 8 mm | 0.13 kg |
| HP300VASP | Vac | Ø 8 mm | 0.13 kg |
